Зарядната станция е чисто нова и е разпечатана за демонстраця. Подържа всички практични и необходими функционалности. Има възможност за създаване на различни сценарии за зареждане през мобилното приложението Smart Llife.

Подробни технически данни:
Brand: Daolar
Model: Y083-32A
Network: WIFI 2.4G / Bluetooth 4.2
APP name: Smart Life
Protection: RCD B
RFID Cards: Support (with 2pcs card)
Charging Record: Support (Format: EXCEL)
Digital screen: Editable
Electrical Connectors for EV: Type 2 / IEC62196
Plug: 5-pin 32A CEE plug (3-phase)
Voltage Range: AC 380V /50HZ
Charging Current: 32A max (6/8/10/12/14/16/18/20/22/24/26/28/30/32A Adjustable )
Maximum Power: 22KW (3-phase)
Schedule charging: 1h-24h
Cable Length: 10M
Cables size: 5X6mm²+0.75mm²
Cable material: Oxygen-free pure copper (TUV certification)
Waterproof & Dustproof: IP55
Leakage protection current: AC≤30mA, DC≤6mA
Leakage protection action time: ≤32ms
Standby power consumption: ≤8W
Type2 plug protection temperature: ≥85°C
Over temperature recovery temperature: ≤75°C
Warranty: 2 Years
Service Life: >10000 times
Connector material: Nylon + PC
Control box Material: ABS + PC Plastic(flame retardant grade UL94-0)
Certification: CE RoHS
Safety protection: Leakage, Short circuit, Overheating, Overvoltage, Overcurrent, Under-voltage, Lightning, CP abnormal
Made in China
