Изграден върху иновативните основи на аплодирания от критиката синтезатор Peak, Novation Summit е синтезатор, който има за цел да вдъхновява, да дава сила, независимо дали на сцената или в студиото.

Неговите цифрови осцилатори New Oxford комбинират най-доброто от аналоговия звук и цифровата гъвкавост, включително вградени и персонализирани цифрови вълнови таблици.

Ефективно поставяйки силата на два Peaks на върха на пръстите ви, Summit позволява две напълно независими пача да бъдат разделени или наслоени през клавиатурата или превключвани между тях в движение. Той също така разширява оформлението на Peak, като много допълнителни контроли и функции вече са достъпни на предния панел.

Технически детайли

50 control knobs;
8 45mm sliders;
1 volume knob;
1 data encoder knob;
Rubberised knob caps with spun metal discs;
55 function buttons;
2 Animate buttons plus hold button;
OLED display;
Kensington Lock;
Power switch;
IEC power supply connector;
USB socket for system (MIDI comms only, no bus power);
MIDI In / Out / Thru;
2 1/4" jack sockets for continuous or switched pedals;
1 3.5mm jack socket for CV in;
2 1/4" jack sockets for left and right outputs;
2 1/4" jack sockets for left and right auxiliary outputs;
2 1/4" jack sockets for left and right inputs;
1/4" jack socket for headphone output;
Metal chassis with American walnut wooden end cheeks;
Metal magnetic inset end pieces.
Software compatibility

Ableton Live Lite is included;
Summit is a USB-MIDI class compliant device.
Power requirements

Maximum power consumption 1A.
Synth engine

16 note polyphony (dependent on voices used per note);
2-part-timbral;
Layered, Split, Dual Bi-Timbral Modes;
5 Voice Modes - Mono, MonoLG, Mono2, Poly, Poly2.
Per voice

3 oscillators;
1 noise generator with HP filter control;
1 ring modulator;
2 LFOs;
1 amp envelope and 2 mod envelopes (ADHSR + looping);
1 filter.
Waveforms include

Sine, tri, sawtooth, square / pulse, plus 43 wavetables of 5 waveforms per row.
Filter

1 state variable OTA filter per voice;
12/24dB slope;
Low-pass / band-pass / high-pass / dual filter (separation of each 12dB filters);
dual filter: LP > HP, LP > BP, HP > BP, LP + HP, LP + BP, HP + BP, LP + LP, BP + BP, and HP + HP;
Pre-filter overdrive;
Post-filter distortion.
Modulation

16 modulation slots per patch;
2 sources per destination per slot.
Mod sources

Direct (depth);
Modulation wheel;
Aftertouch (polyphonic and channel AT);
Expression pedal 1;
Expression pedal 2;
Keyboard velocity;
LFO1 positive;
LFO1 bi-polar;
LFO2 positive;
LFO2 bi-polar;
Amp envelope;
Mod envelope 1;
Mod envelope 2;
Animate 1;
Animate 2;
CV mod input bi-polar;
Bend Up;
Bend Down.
Mod destinations

Oscillator 1-3 frequency, v-sync level, shape amount and level;
Noise source level;
Ring modulator output level;
Overall synth output level;
Filter drive, distortion, cut-off frequency and resonance;
LFO 1 and 2 frequency;
Amp env / mod env 1 / mod env 2 attack, decay and release;
FM Osc 1 -> osc 2, osc 2 -> osc 3, osc 3 -> osc 1 and noise -> osc 1;
Osc 3 -> filter cutoff frequency;
Noise -> filter cutoff frequency.
Effects

FX are per part;
Analogue distortion;
3 chorus types;
Delay with 16 types of delay sync, LP and HP damping, slew and stereo.
FX Mod Matrix source

Direct (depth);
Mod wheel;
Aftertouch;
Expression pedal 1;
Expression/breath pedal 2;
Velocity;
Keyboard;
LFO 1 +/-;
LFO 2 +/-;
LFO 3 +/-;
LFO 4 +/-;
Amp envelope;
Mod envelope 1 & 2;
Animate 1 & 2;
CV +/-;
Bendwheel +/-;
Bend up;
Bend down.
FX Mod Matrix destinations

Distortion level;
Chorus level;
Chorus rate;
Chorus depth;
Chorus feedback;
Delay level;
Delay time;
Delay feedback;
Reverb level;
Reverb time;
Reverb low pass;
Reverb high pass.
Misc.

FM controls on front panel;
Global LFO 3 & 4;
Arpeggiator with key latch – 33 patterns;
Patch storage - up to 512 on hardware (ships with 256 factory patches);
All knobs (excl. volume), sliders and most buttons transmit and receive MIDI cc commands for external control and mapping;
Microtuning with Scala table import and table tuning creation;
Manual mode;
Multi pot mode: Relative, Pot pick-up, Snap
