Говорители 12 броя много запазени

General
Product type Cone driver
Brand Eighteen Sound
Reference 8MB400
Product code ALT080400WF08FC
Informations
Nominal impedance 8 ohm
Dimensional category 8.5 inch
Frequency coverage type Midbass, Midrange, High midrange
Manufacturer sensitivity 95 dB
Calculated sensitivity 93.48 dB
Nominal power handling 280 W
Max power handling 400 W
Bandwidth 55÷5200 Hz
Fundamental parameters
Sd 227 cm²
Mms 18 gr
Cms 348 µm/N
Le 0.96 mH
Re 5 ohm
BL 9.3 T.m
Small signal parameters
Fs 64 Hz
Qes 0.43
Qms 3.23
Qts 0.38
Vas 23.9 L
Datas
Xmax ±5.8 mm
EBP 149 Hz
Fs / Qts 168 Hz
Vas * Qts² 3.46 L
Calculated efficiency 1.4 %
Weight ~3.6 kg
Dimensions
Voice coil diameter 2 inch
Outside diameter 210 mm
Baffle cutout diameter 186 mm
Depth 99 mm
Front thickness 14 mm
Depth after front 85 mm
Shape & Materials
Front chape Cylindrical
Magnet type Ferrite
