Платформа
AMD
Сокет
AMD AM4
Чипсет
AMD B550
Описание
Интерфейси:

USB 2.0
2x USB 2.0
2x USB 3.2 Gen 1 5Gbps (Type-A)
USB 3.2 Gen 2 10Gbps (Type-A)
USB 3.2 Gen 2 10Gbps (Type-C)
HDMI
PS/2 Combo Port
DisplayPort
LAN Port
5x HD Audio Connectors
Flash BIOS Button
Optical S/PDIF OUT
Слотове за разширение:

1x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed
2x PCIe 3.0 x1 slots
Конектори:

1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
6x SATA 6Gb/s connectors
2x M.2 slots (M-Key)
1x USB 3.2 Gen 1 5Gbps Type-C port
1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
6x 4-pin system fan connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
1xTPM module connector
1x Clear CMOS jumper
Съхранение:

6x SATA 6Gb/s ports
2x M.2 slots (Key M)
M2_2 slot (from AMD B550 chipset)
M2_1 slot (from AMD Processor)

Памет:

4x DDR4 memory slots, support up to 128GB
Поддържа DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
Поддържа DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733 / 3866/ 4000/ 4133/ 4266/ 4400+ MHz by A-XMP OC режим
1DPC 1R max speed 4400 MHz
1DPC 2R max speed 3866 MHz
2DPC 1R max speed 4000 MHz
2DPC 2R max speed 3600 MHz
Двуканална архитектура на паметта
Поддържа ECC UDIMM memory (non-ECCрежим)
Поддържа non-ECC UDIMM memory
Поддържа небуферирана памет
