Технически детайли

Сокет: LGA1700;
Чипсет: Intel Z690;
Поддържани процесори: Intel Core 12-та до 14-та генерация;
Поддържана памет: DDR5;
Честота на паметта: 4800 MHz;
Брой слотове за памет: 4;
Звукова карта: ROG SupremeFX 7.1-channel;
LAN: 10/100/1000/2500 Mb/s, WiFi 802.11a/b/g/n/ac/ax, Bluetooth V5.2;
Интерфейси: 1 x Thunderbolt header, 1 x CPU Fan header, 1 x Front panel audio header, 1 x PCI Express 3.0 x1, 1 x PCI Express 3.0 x16 (x4 mode), 6 x SATA 6.0 Gb/s, 2 x USB 2.0 Headers, 1 x USB 3.1 Gen 1 Header, 2 x 8-pin 12V Power connectors, 1 x SPI TPM header, 1 x 24-pin ATX main power connector, 1 x CPU Over Voltage jumper, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 1 x 20-3 pin System Panel header with Chassis intrude function, 1 x M.2 slot Combo (NVMe PCIe 4.0 / SATA), 1 x Thermal Sensor header, 3 x Addressable Gen 2 header, 1 x AURA RGB headers, 3 x M.2 slot (NVMe PCIe 4.0), 5 x 4-pin Chassis Fan headers, 1 x USB 3.2 Gen 2x2 connector, 1 x BMC header, 1 x PCI Express 5.0 x16;
Портове: 1 x HDMI, 1 x DisplayPort, 1 x RJ-45, 1 x Clear CMOS Button, 2 x USB 2.0 Type A, 5 x Audio Jacks, 1 x S/PDIF Out connector, 1 x BIOS Flashback Button, 1 x ASUS Wi-Fi Module, 4 x USB 3.2 Gen 1 Type-A, 2 x USB 3.2 Gen 2 Type-A, 1 x USB 3.2 Gen 2 Type-C;
Форм фактор: ATX;
Размери: 30.5 x 24.4 cm;
